概述

Summary

密封性測量機是在機械部件(低于譽為機械部件)表面充填了示蹤乙炔氣,經過操作時候用內嵌式在監測器里的乙炔氣感測器器測量出從機械部件中滲外漏來的乙炔氣，尋找機械部件和（半）產品的折斷和漏孔等弊端的乙炔氣檢漏轉配?控制類似于啟發測量輪輞的熔接高品質，經過操作時候測量乙炔氣的泄漏量來認定物品沒有是及格。The leak testing machine is filled with tracer gas inside the workpiece (hereinafter referred to as the workpiece), and the gas leaked from the workpiece is detected by the gas sensor built in the detector, then operator can find the product defects of the fracture and leakage. Use this principle to detect the welding quality of the rim, by detecting the amount of gas leakage to determine whether the product is qualified.

手藝特色

本規格型號氣密性性檢側機掌握雙工序檢側APP，要能與此的同時檢側兩根同規格型號的輪輞，也要能與此的同時檢側兩根不同之處規格型號的輪輞，轉備了全規格型號的輪輞檢側塑料模，轉配改換方便快捷高速；This type of leak testing machine with double testing position, which allows to two rims of the same specification or different specifications. The machine is equipped with all kinds of rim testing tools. It is convenient and quickly to install and change.運用二陽極防氧化碳有機廢氣氣體看做測量前言范文，絕對是自然綠色環保，二陽極防氧化碳測量調節器器渾然一體波特率快，可在微妙的時內測量出其最低值的變更登記；Carbon dioxide gas is used as test medium, which is safe and environment protecting. Carbon dioxide test sensor can response quickly and test the change in value in very short time.抗攪擾性強，可在根本冗雜的前提中一直重任，不主受到層結化學成分的材料更改的攪擾，遵循利于使用期長，平靜，節能環保等優勢。It has excellent anti-interference performance. Can work continuously in completed environment and will not be disturbed by atmospheric composition changes. It has long service life, safe and environment protecting.人工操縱需注意1名民工，在線檢測效益每7分鐘5件。At manual mode it requires one worker to operate machine. The test efficiency is 5 pcs. /min.

規格參數

Specification

游戲裝備型號規格	Model Number	Номер модели	QMJC-350
配電網工作電壓	Power Supply	Мощность	AC 380V±10%, 3phase, 50Hz
輪輞上限寬度	Rim Max. Width	Макс. ширина обода	290mm
輪輞主要直徑怎么算	Rim Max. Diameter	Макс. диаметр обода	18 inches
輪輞最長直經	Rim Mini. Diameter	Мини. Диаметр обода	13 inches
良好的密封性件面料矽膠	Material of Sealing Element	Материал уплотнительного элемента	Silica Gel
收緊的氛圍	Pressure of Compressed Air	Давление сжатого воздуха	0.4~0.6Mpa
油缸壓緊氣血	Compressing Force of Oil Cylinder	Сила сжатия масляного цилиндра	2×150KN

布局概述

Structure Summary

超聲波焊接機由電腦主機結構、液壓式傳動鏈配置和設備控制配置五個輪廓線收錄，電腦主機結構收錄：1木材粉碎機機身、2下壓鑄模、 3上壓鑄模 、4 釣魚任務臺、5 油缸 。The leak testing machine consists of three parts: main machine, hydraulic transmission device and electrical control device. The main machine includes: 1 lathe bed, 2 lower tool, 3 upper tool, 4 work platform, 5 oil cylinder.液壓油閥機械傳動安裝工分為油箱開關、油閥—電力設備自動化組、集成系統閥等，電力設備安裝工分為電力設備放肆箱、電力設備使用權箱等。The hydraulic transmission device includes oil tank, oil pump-motor unit group, pile-up valve, etc. The electrical device includes electrical control box and electrical operation box服務器主機和液壓油缸傳輸配備配備在瀝青c30混凝土土基本上，基本見圖下如圖是，電力工程箱結實在屏幕正反。The main machine and hydraulic transmission device are installed on concrete foundation, which is shown on attached drawing. The electrical box is fixed on the side of lathe bed.

輪輞檢測規格

Tested Rim Specification

可測量輪輞規格尺寸下面表：The specification of rim, which can be test is like following chart:

Параметры обода дисков Покупателя Buyer’s Wheel Rim Specs /YST團體活動輪輞樣式
No.數字序號	Параметры обода Rim Spec 輪輞規格為	Диаметр обода Rim Diameter 輪輞的直徑	Ширина обода Rim Width 輪輞高度
1	13X4.5	13 дюймов / inch	4.5 дюймов /inch
2	13x5	13 дюймов / inch	5 дюймов / inch
3	14X5	14 дюймов / inch	5 дюймов / inch
4	14x5.5	14 дюймов / inch	5.5 дюймов /inch
5	14X6	14 дюймов / inch	6 дюймов / inch
6	15X6	15 дюймов / inch	6 дюймов / inch
7	15x7	15 дюймов / inch	7 дюймов / inch
8	16X6	16 дюймов / inch	6 дюймов / inch
9	16X6.5	16 дюймов / inch	6.5 дюймов /inch
10	17x7	17 дюймов / inch	7 дюймов / inch
